In scenarios such as RF communication, radar testing and 5G base stations, accurately monitoring signals without interfering with main path transmission is a core requirement for engineers. The 10dB coaxial directional coupler features a golden coupling ratio of 1:9 (10% coupled, 90% main path retained), making it the optimal component that balances precision and efficiency, and simplifying signal sampling and power monitoring.
Our high-performance 67GHz 10dB RF coaxial directional coupler delivers a precise and reliable signal control solution for your millimeter wave endeavors.
Core Product Highlights
- Millimeter wave band coverage: Frequency range extends up to 67GHz, perfectly supporting cutting-edge 5G/6G communications, satellite systems, millimeter wave radars and advanced R&D testing.
- Precision directional coupling: Boasting a 10dB coupling degree, it enables low-loss transmission of main path signals while providing stable and accurate coupled output, making it an ideal choice for signal sampling, power monitoring and reflection measurement.
- High-performance specifications: With low insertion loss, high directivity and excellent port matching characteristics, it maximizes the signal integrity of the main link.
- Robust industrial design: Precision-engineered with a reliable structure, suitable for harsh operating environments including laboratories, production lines and integrated applications.
Core RF Application Scenarios
- 5G/6G communication systems: RF front-ends of macro base stations and small cell base stations; real-time monitoring of transmit power and antenna feeder reflected power to ensure signal coverage quality and network stability.
- RF test and measurement: Precisely samples RF signals when paired with spectrum analyzers and vector network analyzers, improving the measurement accuracy of R&D and production line quality inspection.
- Radar and electronic countermeasures: Captures radar transmitted signals and target echo signals, facilitating target detection, tracking and jamming signal analysis.
- Industrial/medical RF equipment: Signal monitoring and control for RF heating, magnetic resonance imaging (MRI), RF ablation and other equipment, ensuring safe and efficient operation of the devices.
- Satellite communications/IoT: RF signal distribution and monitoring for low Earth orbit (LEO) satellites and IoT terminals, enhancing the reliability of communication links.
Master the Future of Millimeter Waves, Start with Precision Coupling
In an era of ever-increasing signal rates and frequencies, every decibel of precision is critical. Our 67GHz directional coupler integrates state-of-the-art RF design and manufacturing processes, empowering you to gain precise insights into signal characteristics and effortlessly control system performance.
Contact us now for detailed data sheets, professional application support or customized solutions. Let us join hands to turn your millimeter wave visions into reality.
