·Multi-functional three-coordinate radar

·Altitude Measurement Radar, Altitude Finder

·Millimeter Wave three-coordinate radar

·Export Type Dual Coordinate, Altitude Measurement Radar

·Export Type three-coordinate radar

·Development of Satellite Communication Systems

·Electronic Equipment Support and System Integration Services

·Site Construction and Installation Engineering

·Equipment Life Cycle Maintenance

·Equipment Anti-corrosion and Protection Engineering

·CINRAD/SC

S-band fully coherent Doppler rain measuring radar with a reserved dual-polarization interface. It is capable of monitoring meteorological targets within a radius of 500 km, quantitatively measuring the intensity, radial velocity, and velocity spectrum width of meteorological targets within a range of 250 km, and acquiring dual-polarization information.

·CINRAD/CD

C-band fully coherent Doppler rain measuring radar with a reserved dual-polarization interface. It can monitor meteorological targets within a radius of 450 km, quantitatively measure the intensity, radial velocity, and velocity spectrum width of meteorological targets within a range of 250 km, and obtain dual-polarization information.

·YLD7-D

X-band fully coherent Doppler rain measuring radar. It monitors meteorological targets within a radius of 150 km, quantitatively measures the intensity, radial velocity, and velocity spectrum width of meteorological targets within a range of 75 km, and acquires dual-polarization information.

714CDN、714SDN、714XDN、714KaDPMulti-model airport rain gauging radars and laser wind measuring radars have been deployed at major domestic airports.

·714SDN-K Airport Doppler rain radar

Monitors meteorological targets within a radius of 500 km, quantitatively measures the intensity and wind field of meteorological targets within a range of 250 km, and accurately measures the radial velocity and velocity spectrum width within a radius of 150 km.

·714CDN-K Airport Doppler rain radar

Monitors meteorological targets within a radius of 400 km, quantitatively measures the intensity and wind field of meteorological targets within a range of 200 km, and accurately measures the radial velocity and velocity spectrum width within a radius of 150 km.

·714XDN-K Airport Doppler rain radar

Monitors meteorological targets within a radius of 300 km, and quantitatively measures the intensity, radial velocity, velocity spectrum width, and wind field of meteorological targets within a range of 150 km.

·Cloud fog warning and monitoring radar

Providing high spatiotemporal resolution data for dynamically monitoring the formation and dissipation of clouds and fog, which can be used for dense fog early warning.

714KaDP, Passed the test and evaluation by the Civil Aviation Administration of China in 2017.

Issue warnings for fog within a 15km radius around the airport that affects flight order, monitor the evolution trend of its external contour changes, as well as the development speed of vertical volume for individual fog units.

·Ultra-high Resolution Cloud and Fog Detection

The antenna adopts a parabolic form, with a vertical beamwidth ≤0.1°

Detect the cloud base height and cloud top height within 15km around the airport

Detect low clouds and fog affecting aviation order around airports

Complies with air traffic control business operation requirements

The sole supplier of lightning monitoring and warning radar for important power transmission channels of the State Grid, with a market share of 100%.

·China Meteorological Administration

·Civil Aviation Administration of China

·Capable of monitoring the generation, development, dissipation, and movement status of severe convective weather systems over a range of 400km.

·Effectively monitors and warns against medium-scale storms, heavy rain, wind shear, hail, squalls, and strong winds within a range of 200km.

·The radar can simultaneously achieve full-volume scanning and fixed-direction scanning.

·The radar has multi-beam rapid full-volume detection capabilities, capable of performing a quick volume scan (40 layers) in 1 minute.

Main Specifications：

·Source-fed slotted waveguide antenna

·Beamwidth: ≤1°; ≤0.5°

·Antenna dimensions: 8.9m × 8.8m

·Transmitting pulse power: ≥14kW

·Number of simultaneous beams: ≥20
