YX-BT-50K-50G-2.4(F&M)
50kHz~50GHz Bias Tee
- YX-BT-50K-50G-2.4(F&M)
- In stock
Please contact us if you need more units than what is available online.
BULK PRICING
| TECHNICAL DETAILS | |
|---|---|
| Minimum Frequency(KHz) | 50 |
| Maximum Frequency（GHz) | 50 |
| Insertion loss(dB)(dB) | 3.2 |
| Isolation(dB) Min(dB) | 30 |
| VSWR | 2.0:1 |
| RF Power Max(W) | 2 |
| Voltage Max(Vdc) | 35 |
| Current Max(mA) | 500 |
| Impedance | 50Ω |
| Connector | RF IN-2.4mmFemale/RF&DC-2.4mm Male/DC-SMA Female |
